Key Advantages

Intelligent Light Welding Special System

Easy to move and fast to install

welding quality is guaranteed

Reduce costs, increase efficiency, and enhance digital iz ation

Flexible matching and continuous upgrading

Technical Specifications

Accessories

Main application industries

Selection

How to Choose a Robotic Arm

DS1003F‑062 (Working Radius 622mm): Small parts, short welds, small components, compact workstations

DS1005F‑092 (Working Radius 922mm): Versatile mainstream model, preferred choice for the vast majority of steel structure weldments

DS1010F‑140 (Working Radius 1400mm): Large components, long welds, suitable for wide operating ranges

Selection Guide

Long-term full-load workshop production → Prioritize MWC‑A Water-Cooled Model

On-site construction, frequent equipment moving, intermittent operation → Prioritize MWC‑B Air-Cooled Model

Large weld seam spans → Prioritize the 1400mm long arm; Standard workpieces → 922mm offers the best value for money.

Robot Arm Selection Guide

• DS1003F-062 (Reach: 622 mm)：For small-size workpieces, short welds and compact-layout workstations.

• DS1005F-092 (Reach: 922 mm)：General-purpose mainstream model, preferred for most steel-structure welding parts.

• DS1010F-140 (Reach: 1400 mm)：For large components, long weld seams and applications requiring wide working coverage.

Selection Recommendations

• For long-duration full-load production in workshops → Prioritize the MWC-A water-cooled model.

• For site-based jobs, frequent relocation and intermittent operation →Prioritize the MWC-B air-cooled model.

• Choose the 1400 mm long-reach arm for workpieces with large-span welds. The 922 mm arm delivers the best cost-performance for general-purpose parts.

FAQ

Q1: Is it easy-to-use for workers without robot programming experience? A: Drag-and-teach and graphical programming are supported. Welders can directly drag the robot arm to trace welding paths, and simply set welding parameters. No-code operation is available. Ordinary welders can master the operation after several hours of training.

Q2: How to choose between water-cooled and air-cooled versions? Can I upgrade to water-cooled later? A: The water-cooled version is designed for long-time continuous high-current welding. The air-cooled version fits intermittent welding and frequent on-site relocation. Due to different overall machine structures, air-cooled units cannot be retrofitted to water-cooled. Please confirm the version during model selection.

Q3: Does the equipment require floor fixing installation? A: Equipped with mobile casters, the whole unit can be moved freely. No foundation fixing is required. Just connect gas and power after positioning, then it is ready for operation.

Q4: Is vision tracking available as an option? A: Yes. Vision seam tracking is an optional accessory. It realizes automatic seam deviation correction and works well for workpieces with large assembly tolerance.

Q5: Can positioners and fixtures be integrated for turn-key solutions? A: Yes. The workstation supports flexible expansion with positioners and tooling fixtures. We can supply complete turn-key welding solutions.
