Supports solid-core & flux-cored welding wires, one-key function switching, gas-detection safety and self-locking function.
Suitable for carbon steel, low-carbon steel, alloy steel; widely used in high-speed train, pressure vessel, vehicle modification, yacht, high-voltage switch manufacturing.
Compact size, supports external wire feeder & manual welding; easy 2T/4T switching
Controllable current for stable arc; arc-off function prevents wire sticking
Soft-switching for precise waveform; ultra-low spatter for varied materials, gases and wires in short-circuit transfer
Fully-digital high-integration, low failure rate. Support software upgrade, dedicated carbon-steel program
Compatible with robots & PLCs, DEVICENET supported; store & recall welding parameters
Multiple safety protections with fault-code alarm for reliable & safe operation
ltem | NBC-350S |
|---|---|
Rated input voltage Frequency | Three phase 380V±10% 50Hz |
Rated input power (KVA) | 15 |
Rated input current (A) | 23 |
Rated output voltage (V) | 31.5 |
Rated load persistence rate (%) | 80 |
Output no-load voltage (V) | 72 |
Output current range (A) | 60-350 |
Output voltage range (V) | 14-40 |
Welding wire | 0.8/1.0/1.2 |
Gas flowing capacity (L min) | 15-25 |
Torch cooling type | Air |
Shell protection level | IP21S |
Insulation level | H |
Overall size L×W×H (mm) | 550×305×490 |
Weight (Kg) | 24 |
Standard Spec. air cooling | Standard spec. Water cooling | Optional accessory |
|---|---|---|
One set of wire feeding machine (5-meter cable) | One set of water-cooled wire feeding machine (with 5 meters of cable) | Gas proportioning unit |
1 set of 3-meter gas-cooled welding gun (with Panasonic interface) | 1 set of 3-meter water-cooled gun (European interface) | Water tank |
One set of 2-meter grounding wire cable | One set of 2-meter grounding wire cable | Welding machine cart |
CO (AC36V 25L min) | CO (AC36V 25L min) | |
One CO2 gas meter (AC36V 25L/min) | One CO2 gas meter (AC36V 25L/min) |
